Automatic Filter Integrity Tester
Automatic Filter Integrity Tester Automatic Filter Integrity Tester

Automatic Filter Integrity Tester

Item No.: SIIC-FT223
INDRO automatic filter integrity tester is designed for inspecting the integrity of all kinds of absolute rated filters, such as pleated filter cartridge, capsule filter and syringe filter etc. It has variety of standard functions, including forward flow
INQUIRY
Description
INDRO Automatic Filter Integrity Tester
This Model FT223 of automatic filter integrity tester is designed for inspecting the integrity of all kinds of absolute rated filters, such as pleated filter cartridge, capsule filter and syringe filter etc. It has variety of standard functions, including forward flow test, bubble point test, water intrusion test, pressure hold test and automatic self-test. Developed in accordance with GAMP guidelines, and offering full compliance with 21 CFR Part 11, Audit Trails and CSV (Computerized System Verification) requirements. INDRO provides the complete validation protocols for the FT223 including lQ, OQ and PQ.

Working principle


Features:
-Powerful CPU
Fully automated, fast test speed to guarantee the accurate calculation and save labor cost
-Four test method
Water intrusion, bubble point, forward flow, pressure decay
-Easy to use
10-inch touch-screen color display with graphic
-IP 54 Splash and dust proof
-Graphic Display
-Test report output in PDF format
-Easy to clean
Suitable for using in cleanroom
-4-Level user privilege
21 CFR Part 11 complaint, audit trails
-Built-in printer
Can print the test repot, historical data and graphic and will not generate particles.
-Excellent software
Large storage for recipes management, data query and faults reminder.
Software updating service is provided.
-Self-test function
Once turn on, it will do self-test, which can prevent false-positive results and improve the traceability of deviation.
-Automation control
External solenoid valve, automation control to prevent the gas back, ensure pollution-free for the product and the instrument.

Specifications
-With 21CFR part 11 compliance with user access and password policy
-Data export in PDF and CSV format is possible
-Repot print in built-in thermal print and A4 size print with any windows printer
-System Data and Audit log backup and restore facility available
- Data Storage: 64GB RAM stored 250000 data memory
- System Configuration: Intel CPU 1.6 GHz windows 10 pro, 4GB RAM

Technical parameters
Input Voltage: 100-240VAC
Input Frequency: 50/60Hz
Input Power: 160W
Fuse: <5.0A
Dimension (L*W*H):  360mm*280mm*280mm
Operating Temperature: (5~50) ℃
Storage Temperature: (-10~60) ℃
Ambient Humidity: <85%, non-condensing
Pressure Units: mbar, psi, kpa

Test range
Forward Flow: (0.1-600) ml/min
Water Intrusion: (0.01-100) ml/min
Bubble Point: (100-8000) bar
Pressure Maintenance: (100-8000) mbar

Test Accuracy
Forward flow: ±0.1ml/min
Water Intrusion: ±0.02ml/min
Bubble Point: ±50mbar

Recipe Management
- Multiple recipes can be create.
-Individual recipe create/edit for Bubble point, Water intrusion & Forward flow tests.
-Incorporation of housing details, product details in recipe.

User Management
- Creation of multiple users with different Privilege levels.
- Enable/Disable of user function.

Applications
-Instrument can be used for injection filter, capsule filter, membrane filter, cartridge filter
-Highly applicable for Filter M/F & Pharmaceuticals area.

Benefits
- Easy to use.
- Precise close loop control of pressure measurements.
- User friendly HMI display.
- Can be compatible with Network printers.
- Paperless PDF print for secure records.
